Neosonic Bracket Kit

Neosonic Bracket Kit

Overview

The Neosonic bracket offers our new generation fit range with a large offset to suit a range of applications.

This bracket is designed to give riders the option to move the armrests well behind the basebar in order to adopt a compact position.

  • Well suited to use with road and gravel bikes to allow a comfortable aero position without moving the saddle.
Tech Specs
  • Bracket:Ā NeosonicĀ (6061-T6 aluminum)
  • Armrest Stack:Ā 42.5mm
  • Armrest Offset:Ā 25mm
  • Armrest Width Adjustment:Ā 37mm
  • Handlebar Clamp Diameter:Ā 31.8mm
  • Extension Clamp Diameter: 22.2mm
  • Color: Black
  • Weight:Ā 256g
Tech Guide

Torque settings (all bolts are M6)

  • Bar Clamp:Ā 6Nm
  • Extension Clamp:Ā 6Nm
  • Armrest Bolts:Ā 4.7Nm
Manual

Neosonic Bracket Kit Installation Instructions

$46.74
